Classic Series
The CUA Series efficiently separates the internal and external components of cables for recycling. The integrated system, consisting of granulation, separation, and fan units, effectively shreds and separates 99.6% of cable components. Materials can be fed manually via a conveyor belt or automatically with the SSH Series Pre-Shredding Machine equipped with smart PLC software. Its compact structure and user-friendly PLC touch-screen control panel make management easy. The CUA Series enhances durability with high-quality components and is CE-certified. Available in three models: CUA S, CUA M, and CUA L.
Recyclable Materials
Technical Specification
| CUA S | |
|---|---|
| FEATURE | VALUE |
| TOTAL POWER | 40 kW / 53.6 HP |
| GRANULATOR MOTOR | 30 kW / 40.2 HP |
| BLADE QUANTITY | 3+2 |
| OVERALL LENGTH | 2.500 mm / 98.4" |
| OVERALL WIDTH | 2.300 mm / 90.5" |
| OVERALL HEIGHT | 2.450 mm / 96.4" |
| OVERALL WEIGHT | 2.700 kg / 5,950 lb |
| APPROXIMATE CAPACITY | Up to 400 kg/h |
| APPROXIMATE CAPACITY | Up to 900 lb/h |
| CUA M | |
|---|---|
| FEATURE | VALUE |
| TOTAL POWER | 80 kW / 107.2 HP |
| GRANULATOR MOTOR | 55 kW / 73.7 HP |
| BLADE QUANTITY | 40+4 |
| OVERALL LENGTH | 5.280 mm / 207.8" |
| OVERALL WIDTH | 2.000 mm / 78.7" |
| OVERALL HEIGHT | 2.860 mm / 112.5" |
| OVERALL WEIGHT | 5.000 kg / 11,020 lb |
| APPROXIMATE CAPACITY | Up to 800 kg/h |
| APPROXIMATE CAPACITY | Up to 1800 lb/h |
| CUA L | |
|---|---|
| FEATURE | VALUE |
| TOTAL POWER | 120 kW / 160.9 HP |
| GRANULATOR MOTOR | 90 kW / 120.6 HP |
| BLADE QUANTITY | 60+6 |
| OVERALL LENGTH | 6.270 mm / 246.8" |
| OVERALL WIDTH | 2.250 mm / 88.5" |
| OVERALL HEIGHT | 3.200 mm / 125.9" |
| OVERALL WEIGHT | 6.500 kg / 14,330 lb |
| APPROXIMATE CAPACITY | Up to 1300 kg/h |
| APPROXIMATE CAPACITY | Up to 2900 lb/h |
